How to create a segment-triggered flow

Last updated at:

You will learn

Learn how to create segment-triggered flows which are used to email subscribers when they are added to a segment. In most cases, date property-, list-, or metric-triggered flows can more efficiently accomplish what can be done with a segment triggered flow.

Contacts can only receive a segment-triggered flow once. This is why if you're building a post-purchase flow, for example, you should use a metric-triggered flow instead of a segment-triggered one. Even though it is possible to build a segment of customers who placed an order, a metric-triggered flow is more appropriate in this case because you likely want customers to receive a post-purchase every time they buy, not just the first time.

Apple Mail Privacy Protection (MPP), which was released with iOS15 and updates to other Apple devices, may lead to inflated open rates due to changes in how we receive open rate data.

If you are triggering flows off of opens themselves, we suggest creating a custom report that includes an MPP property to review these affected opens. You can also identify these opens in your individual subscriber segments.

Configure a segment-triggered flow

To create a segment-triggered flow from scratch:

  1. Navigate to the Flows tab.
  2. Click Create Flow.
  3. Click Create From Scratch in the top right.
  4. Name your flow and click Create Flow.
  5. In the Trigger Setup sidebar, click Segment.
    Select the Segment option from the list of triggers from Trigger Setup pane in the lefthand sidebar
  6. In the dropdown, select the name of your segment.

Once you set a particular segment to trigger the flow, you will not be able to change it to a different segment. In order to do this, you will need to clone the flow and change the segment that triggers the flow.

How a segment-triggered flow works

Whenever someone is added to the segment you select, they will enter the flow.

Customers enter segments through actions (e.g., placing an order or opening an email) as close to real-time as possible. However, if you have a higher volume of customers entering segments, you may see a brief delay (up to one hour) in these updates. More information on the timing of segment updates can be found in our article on how segments update.

Contacts can only receive a segment-triggered flow once. If someone is removed from a segment and then re-added to that same segment, they will not re-trigger the flow. If someone is removed from a segment before the end of the flow, they will stop receiving the email sequence.

If you manually update a segment that's set up to trigger a flow, new members who instantly populate due to the update will not automatically enter the flow. When a flow is triggered by a segment, only those who are added to the segment organically, based on the established segment definition, will be scheduled.

When you create, edit, or update a segment, new populated members will not be queued by default. This ensures if you make a mistake with your definition or don't immediately want all members of a segment to enter a flow, you don't have to worry. If you do want to push all members of a segment into a connected flow after manually updating the definition, you will need to back-populate the flow

At send time, Klaviyo checks to ensure that each potential recipient is still part of the segment triggering the flow. Say, for example, you edit the definition of a segment and some of the contacts queued up for the connected flow no longer meet the segment's conditions. At send time, we will re-verify that these recipients qualify and, when they fail the check, they will be skipped.

Recipients will only receive emails within a flow if they are still a member of the connected segment at send time.

Additional resources

Learn about other flow types:
